Ideal 4000 Aluplast
LTB WINDOWS & DOORS
The strong profile design and large chambers for steel reinforcements guarantee good static parameters. The Ideal 4000 Aluplast profile allows large windows to be made, and the multi-chamber construction ensures high thermal and acoustic insulation.
Profile Design
-
Installation depth 70-85 mm
-
Width of frame/sash combination from 89 mm
-
Maximum glazing thickness up to 48 mm
-
Number of chambers 5-6
-
External sealing system (2 gaskets)
-
Steel reinforcement system
-
Available profiles design classic-line, round-line
-
Heat transfer coefficient Uf= 1.3 – 1.4W/m2K
-
Wind resistance C4*.
-
Water tightness 9A*
-
Air permeability 4*
-
Sound insulation with 4/16/4 glazing 34(-2;-5)dB
-
Maximum sound insulation 45(-1;-3)dB*
-
Foam option yes
-
Replaceable gaskets yes
Window Advantages
Colours Ideal 4000 Aluplast
PLEASE NOTE: The full range of colours, including non-standard veneers, is available in our showrooms and in the sales network of our Business Partners.
The presented graphic materials are for illustrative purposes only and the actual colours and textures of the products may differ from those shown in the advertising materials.
The presented graphics, including the presentation of colours, cannot constitute grounds for a complaint.
